RED1800.5 – 1800W Class-D 5-Channel Car Audio Amplifier
Available in stock (15)
Power your entire system with a single amplifier. The Recoil RED1800.5 delivers clean, efficient Class-D performance across five channels, making it the perfect solution for driving your front and rear speakers while supplying serious power to your subwoofer.
Designed for daily reliability and outstanding sound quality, the RED1800.5 combines compact dimensions with high-output performance, allowing you to build a powerful system without sacrificing valuable installation space. Whether you're upgrading a factory system or building a full aftermarket setup, the RED1800.5 provides the flexibility and power to do it all.
Features
- 1800 Watts Max Power
- Full-Range Class-D Technology
- 5-Channel Design
- Stable down to 2Ω on full-range channels
- 1Ω Stable Mono Subwoofer Channel
- Variable High-Pass & Low-Pass Crossovers
- Bass Boost Control
- MOSFET Power Supply
- 4-Way Protection Circuit (Thermal, Voltage, Short Circuit & DC Offset)
- Compact Chassis for Easy Installation
- High-Level & Low-Level Input Compatibility
Performance Specifications
| Model | RED1800.5 | |
| 4-channel |
mono |
|
| Power @1Ohm (14.4V) |
1200W x 1 |
|
| Power @2Ohm (14.4V) |
220W x 4 |
880W x 1 |
| Power @4Ohm (14.4V) |
140W x 4 |
550W x 1 |
| Power (Bridged) @4Ohm (14.4V) |
420W x 2 |
N/A |
| Operating Voltage |
9V-16V |
9V-16V |
| Idling Current (Power On) |
2100mA |
|
| Frequense Response |
10Hz-20kHz |
10Hz-250Hz |
| Signal to Noise Ratio (SNR) |
85dB |
94dB |
| THD+N (@1W) |
<0.02% |
<0.06% |
| Input Sensitivity(Low Level) |
220mV-12V |
|
| Bass Boost |
N/A |
0-12dB |
| Subsonic Filter |
10Hz-50Hz |
|
| Crossover LPF |
50Hz-5kHz |
55Hz-300Hz |
| Crossover HPF |
55Hz-5.5kHz |
|
| Bass Remote |
Yes |
|
| Clip Indication |
2% |
|
| Dimensions |
14.56"x7.59"x2.2"(370x193x56) |
|
| Fuse Rating |
200A |
|
| Voltage Protection |
9V-16V, Self-recovery |
|
| Over-Load Protection |
Yes, Self-recovery |
|
| Over-Current Protection |
Yes, Self-recovery |
|
| Speaker Wire Short Circuit Protection |
Yes, Self-recovery |
|
| Thermal Protectoin |
Yes, Self-recovery |
|
| DC Power Reverse Protection |
Yes |
|
| Speaker Wire/Power Wire Mix Protection |
Yes, Restart recovery |
|
